Don't forget to purchase a shaft bullet (listed below). There's nothing worse than having to rebuild your shocks twice, simply because you tore a seal when you were reassembling your shock. This cheap tool saves a lot of headache and time spent in rebuilding your Fox shock absorber.
803-00-683-A Kit Includes:
Shock Body Seals:
1 Wiper seal for the bearing cap
1 Wiper seal for the shaft bearing / shaft guide
1 Internal o-ring for the shaft bearing / shaft guide
1 External o-ring for the shaft bearing / shaft guide
1 Thin o-ring that goes underneath the shock piston wear band
Reservoir Seals:
1 Soft wear band for the reservoir's piston
1 Thick o-ring for the reservoir's piston
2 O-rings for both end caps of the reservoir
Bypass Seals:
8 O-rings for the bypass adjusters (enough to do 4 adjusters)
Shock Body Seals:
Reservoir Seals:
Bypass Seals:
